MSI MAG A850GL Gaming Power Supply

Product Specifications

• WEIGHT (CARD)
  • 169g
• Dimensions
  • 120mm x 120mm x 25.6mm
• Modular
  • Yes (full modular)
• Fan Bearing
  • Fluid Dynamic Bearing
• Bearing Type
  • Hydro-Dynamic Bearing
• Rated Speed
  • 500 - 1800 ±15% RPM
• Power Watt
  • 850W
• Input Voltage Range
  • 100-240V~
• Power Excursion
  • 1870W (*up to 220% of the PSU's rated power for 100μs)
• Air Flow
  • 19.79 - 71.27 CFM
• Static Air Pressure
  • 0.16 - 2.09 mm-H20
• Input Frequency
  • 47-63 Hz
• ATX (24 pin)
  • 1
• Connector
  • 4-Pin PWM/DC
• Efficiency
  • 80 PLUS Gold (up to 90%)
• EPS (8 pin)
  • 2
• Life Expectancy
  • MTTF 150,000 Hours (25℃)
• PCI-E 5.1 (16 pin)
  • 1 (600W)
• Fan Size
  • 135 mm
• Dimension
  • 150 x 150 x 86 mm
• PCI-E (6+2 pin)
  • 4
• PFC Type
  • Active PFC
• SATA (15 pin)
  • 8
• Protection
  • OCP/ OTP/ OPP/ SCP/ OVP/ UVP/ SIP/ NLO
• MOLEX (4 pin)
  • 3
• FDD (4 pin)
  • 1
• UPC
  • 0824142398081
